Perlube AW-Series
Hydraulic Oils
Description
The Perlube AW-Series of oils are outstanding hydraulic and circulating oils designed to provide maximum service life in hydraulic systems, heat transfer systems, gear cases, friction clutches, and other industrial multifunctional applications. The Perlube AW-Series oils have been “double-treated” with anti-wear additives to produce a truly service-efficient oil.
Key Properties
• Superior thermal and hydrolytic stability • Inhibited to prevent foaming and sludge formation • Effective demulsibility properties provide for rapid water separation • Outstanding anti-wear features; excellent film strength & load-carrying characteristics • Formulated to meet performance levels of all major hydraulic equipment manufacturer requirements & specifications
Name
ISO Grade
ASTM Color
Viscosity @ 100°F
Flash Point °F
Specific Gravity
AW-10
10
1
57.6
260
0.85
AW-15
15
1
75.8
380
0.8
AW-22
22
1
105
380
0.86
AW-32
32
1
149
380
0.87
AW-46
46
1
214
380
0.87
AW-68
68
1
317
410
0.88
AW-100
100
1
468
410
0.88
AW-150
150
1
709
410
0.88
AW-220
220
1
1047
410
0.89
Perlube WL-Series
Slidway Oils
Description
Perlube WL-Series are outstanding, multipurpose lubricating and machine tool slideway oils designed to provide excellent machine tool performance. Perlube WL-Series are superior lubricating oils with excellent oxidation and corrosion protection as well as unsurpassed water separation characteristics. Perlube WL-Series have load carrying and staying properties that make them excellent way lubricants.
Key Properties
• Outstanding stick-slip friction prevention • Exceptional oxidation & corrosion protection • Built with demulsibility properties for rapid water separation • Excellent load-carrying & staying properties for effective lubrication • Passes Bijur Filterability & ASTM D-2711 Demusibility performance tests • Formulated to meet performance levels of all major manufacturer requirements & specifications
Name
ISO Grade
ASTM Color
Viscosity @ 100°F
Flash Point °F
Specific Gravity
WL-22
22
1
98
380
0.86
WL-32
32
2
149
380
0.87
WL-46
46
2
214
380
0.88
WL-68
68
2
317
420
0.88
WL-100
100
4
468
420
0.88
WL-150
150
4
709
420
0.89
WL-220
220
4
1047
460
0.89
Perlube EP-Series
Gear Oils
Description
The Perlube EP-Series of oils are premium lubricating and gear oils that contain outstanding rust and oxidation protection, superior demulsibility, and long-lasting extreme pressure additives. They are engineered to lubricate even under severe heat and load conditions in enclosed gear sets, ways, bearings, sliding surfaces, and related heavy-duty applications.
Key Properties
• Superior oxidation and thermal stability • High performing under severe heat and load conditions • Effective demulsibility properties provide for rapid water separation • Recommended for all industrial enclosed gearing and wherever an AGMA extreme pressure lubricant is required • Formulated to meet the performance levels of all major manufacturer requirements and specifications
Name
ISO Grade
ASTM Color
Viscosity @ 100°F
Flash Point °F
Specific Gravity
EP-32
32
1
149
350
0.87
EP-46
46
1
214
350
0.88
EP-68
68
2
317
420
0.88
EP-100
100
3
450
420
0.89
EP-120
120
4
555
450
0.89
EP-150
150
4
709
450
0.89
EP-220
220
4.5
1047
480
0.9
EP-320
320
5
1533
500
0.9
EP-460
460
5
2214
550
0.91
EP-680
680
7
3298
550
0.93
Perlube RO-Series
Turbine Oils
Description
The Perlube RO-Series of oils are outstanding hydraulic, circulating, and lubricating oils that are designed for premium quality applications where anti-wear features are not required.
Key Properties
• Superior rust & oxidation protection / thermal & hydrolytic stability • Contains metal deactivators to protect metal surfaces • Completely demulsifies, providing rapid water separation • Meets Cincinnati Milacron P-38, P-54, P-55, & P-57 specs • Inhibited to prevent foam & sludge formulation, which are common causes of filter blockage • Formulated to meet performance levels of all major manufacturer requirements & specifications
Name
ISO Grade
ASTM Color
Viscosity @ 100°F
Flash Point °F
Specific Gravity
RO-22
22
1
98
320
0.86
RO-32
32
1
149
350
0.87
RO-46
46
2
214
350
0.88
RO-68
68
2
317
350
0.88
RO-100
100
3
468
420
0.89
RO-150
150
4
709
420
0.89
RO-220
220
5
1047
420
0.89
RO-320
320
5
1533
420
0.9
Perlube S-Series
Spindle Oils
Description
The Perlube S-Series are manufactured from high-quality premium base stocks for the purpose of lubricating high speed bearings such as the spindles of machine tools. Perlube S-Series oils are designed to lubricate, prevent wear, cool, and prohibit sludge and deposit formation.
Key Properties
• Clear appearance & non-staining • Additive package to reduce starting torque & minimize wear • Excellent lubricity lowers power consumption & reduces bearing temperatures • Formulated to meet performance levels of all major manufacturer requirements & specifications • Ensures the proper flow of lubricant by minimizing the formation of oxidation & deposition of sludge, gum, or resin • Excellent metal wetting properties, providing top cooling & lubrication performance for extended spindle bearing life
Name
ISO Grade
ASTM Color
Viscosity @ 100°F
Flash Point °F
Specific Gravity
S-2
2
0.5
32.8
200
0.8
S-3
3
0.5
36
200
0.82
S-7
7
1
47.2
265
0.84
S-10
10
1.5
576
280
0.85
S-22
22
1.5
105
410
0.87
